HALLOMOTOR M620 G510 48V/52V 1000W Mid Drive Motor Conversion Kit with DPC18 Display User Manual

1. Gabatarwa

This manual provides essential information for the installation, operation, and maintenance of your HALLOMOTOR M620 G510 Mid Drive Motor Conversion Kit. This kit is designed to convert a standard bicycle into an electric bicycle, offering enhanced power and performance. Please read this manual thoroughly before installation and use to ensure safe and optimal operation of your e-bike system.

Hoto 1: Example of a bicycle converted with the HALLOMOTOR M620 G510 Mid Drive Motor Kit.

2. Bayanin Tsaro

Always prioritize safety when working with or operating your e-bike conversion kit. Failure to follow safety instructions can result in serious injury or damage to the product.

• Karanta Duk Umarni: Familiarize yourself with all components and procedures before beginning installation or operation.
• An Shawarar Shigar Ƙwararru: If you are unsure about any step, seek assistance from a qualified bicycle mechanic.
• Saka Kayan Kariya: Always wear a helmet and appropriate safety gear when riding your e-bike.
• Duba Haɗin kai: Ensure all electrical connections are secure and waterproof before riding, especially after rain or washing.
• Tsaron Baturi: Use only compatible batteries. Do not short-circuit, puncture, or expose the battery to extreme temperatures.
• Dubawa na yau da kullun: Periodically check all bolts, cables, and components for tightness and wear.
• Bayyanar Ruwa: While the motor has an IP65 waterproof rating, avoid submerging the motor or exposing electrical connections to high-pressure water jets.
• Dokokin gida: Be aware of and comply with all local laws and regulations regarding e-bike use.

3. Abubuwan Kunshin

Carefully unpack the box and verify that all items listed below are present and undamaged. If any items are missing or damaged, contact your vendor immediately.

Image 2: All components included in the conversion kit.

• 1 x 48V/52V 1000W Mid Drive Motor (UART Protocol)
• 1 Pair x Brake Levers
• 1 Pair x Crank Arms
• 1 x 44T Chainwheel
• 1 Set x Thumb Throttle
• 1 Set x Speed Sensor
• 1 x DPC18 Display
• 1 x 4-in-1 Cable
• 1 Set x Accessories (mounting hardware, lock nuts, etc.)

4. Saita da Shigarwa

The installation of the M620 G510 mid-drive motor requires careful attention to detail. It is crucial that the bicycle frame's bottom bracket area is compatible and prepared correctly for the motor's dimensions.

1. Prepare the Bicycle Frame: Ensure the frame adapter and bicycle frame are properly aligned. For optimal fit and concentricity, the frame's bottom bracket area may require heat treatment after welding to match the motor's installation dimensions and mounting hole locations.
2. Mount the Motor: Align the three mounting holes on the motor with the corresponding holes on the bicycle frame's bottom bracket. Carefully fit the motor into position.
3. Secure the Motor: Use the provided accessories and mounting hardware to firmly secure the motor to the frame. Ensure all bolts are tightened to the manufacturer's specifications.
4. Install Crank Arms and Chainwheel: Attach the crank arms and the 44T chainwheel to the motor's shaft.
5. Install Brake Levers and Thumb Throttle: Mount the brake levers and thumb throttle onto the handlebars.
6. Install DPC18 Display: Secure the DPC18 display to the handlebars in a position that is easily visible and accessible.
7. Haɗa Waya: Use the 4-in-1 cable to connect the display, throttle, brake levers, and speed sensor to the motor. Ensure all connections are snug and correctly oriented (refer to wiring diagram if available).
8. Install Speed Sensor: Mount the speed sensor on the chainstay and align the magnet on a spoke of the rear wheel.
9. Haɗa Baturi: Connect your compatible 48V or 52V battery to the motor system. Ensure the battery is securely mounted on the bicycle.
10. Dubawa na farko: Before riding, perform a thorough check of all installed components, connections, and ensure the brakes and gears function correctly.

Image 3: Mid-drive motor installed on a bicycle.

5. Umarnin Aiki

The DPC18 display serves as the Human Machine Interface (HMI) for your HALLOMOTOR M620 G510 system, providing essential information and control over the motor's functions.

Image 4: DPC18 Display and motor connections.

5.1 DPC18 Display Overview

The DPC18 display features a high-contrast LCD screen designed for clear readability, even in direct sunlight. Its compact design offers protection against water and dust (IP65 rated).

• Kunnawa/Kashewa: Danna ka riƙe maɓallin wuta a kan allon don kunna ko kashe tsarin.
• Zaɓin Matsayin Taimako: Use the up/down buttons to cycle through different levels of pedal assist (e.g., 0-5 or 0-9, depending on configuration).
• Nuni Bayani: The screen shows real-time data such as current speed, battery level, assist level, trip distance, odometer, and more.
• Taimakon Tafiya: Some displays offer a walk assist function, typically activated by holding the down button, which provides low-speed motor assistance for pushing the bike.
• Menu Saituna: Access the settings menu (refer to the DPC18 specific manual for detailed navigation) to customize parameters like wheel size, speed limit, and unit preferences.

5.2 Amfani da Babban Yatsa

The thumb throttle provides on-demand power without pedaling. Apply gentle pressure to the throttle to engage the motor. Always use the throttle responsibly and be aware of your surroundings.

5.3 Brake Levers with Cut-off Sensor

The included brake levers are equipped with motor cut-off sensors. Engaging either brake lever will immediately cut power to the motor, enhancing safety during braking.

6. Kulawa

Regular maintenance ensures the longevity and reliable performance of your HALLOMOTOR M620 G510 conversion kit.

• Tsafta: Keep the motor, display, and electrical connections clean. Use a damp cloth to wipe surfaces. Avoid high-pressure washing directly on electrical components.
• Duban Kebul: Periodically check all cables and connectors for signs of wear, fraying, or damage. Ensure they are securely plugged in.
• Duban Fastener: Regularly inspect all mounting bolts and fasteners on the motor, display, and other components. Tighten any loose fasteners to prevent vibration damage.
• Sarka da kuma hanyar tuƙi: Maintain your bicycle's chain and drivetrain (chainwheel, cassette, derailleur) as you would a regular bicycle. Keep the chain clean and lubricated.
• Kulawar Baturi: Follow the battery manufacturer's instructions for charging, storage, and maintenance. Avoid fully discharging the battery and store it in a cool, dry place.
• Hayaniyar Motoci: If you notice unusual noises from the motor, discontinue use and inspect for any issues.

7. Shirya matsala

Wannan sashe yana ba da mafita ga matsalolin da za ku iya fuskanta. Don ƙarin matsaloli masu rikitarwa, tuntuɓi tallafin fasaha.

8. Ƙayyadaddun bayanai

Key technical specifications for the HALLOMOTOR M620 G510 Mid Drive Motor Conversion Kit.

Image 5: Technical specifications and dimensions of the motor.

9. Garanti & Tallafi

HALLOMOTOR products are typically covered by a manufacturer's warranty against defects in materials and workmanship. The specific terms and duration of the warranty may vary. Please retain your proof of purchase for warranty claims.

9.1 Da'awar Garanti

In the event of a warranty claim, please contact your original point of purchase or HALLOMOTOR customer support with your product details and proof of purchase. Do not attempt to repair the motor or components yourself, as this may void the warranty.

9.2 Tallafin Fasaha

For technical assistance, troubleshooting beyond this manual, or inquiries about parts, please contact HALLOMOTOR customer service. Provide your product model number and a detailed description of the issue to receive efficient support.

Contact information for HALLOMOTOR support can typically be found on their official website ko ta hanyar dillalin ku.
