1. Gabatarwa
Thank you for choosing the NEBO Luxtreme 500-Lumen LED Flashlight. This manual provides essential information for the safe and effective use, maintenance, and troubleshooting of your new flashlight. Please read it thoroughly before operation and retain it for future reference.
2. Bayanin Tsaro
- Kar a kalli kai tsaye cikin fitilun hasken LED don guje wa raunin ido.
- A kiyaye nesa da yara.
- Do not attempt to disassemble the flashlight, as this may void the warranty and cause damage.
- Use only the specified charging cable and power source to prevent damage to the battery or flashlight.
- Ka guji fallasa hasken walƙiya zuwa matsanancin zafi ko hasken rana kai tsaye na tsawon lokaci.
3. Abubuwan Kunshin
- NEBO Luxtreme 500-Lumen LED Flashlight
- Rechargeable Lithium Ion Battery (pre-installed)
- USB-C Cajin Cable
4. Kayan Samfura
- Fitar LED mai haske: Delivers 500 lumens of bright LED light.
- 4 Yanayin Haske: Offers versatile lighting options for various situations.
- Extended Beam Distance: Projects a focused light beam up to 900 meters (approximately half a mile).
- Karami kuma Mai ɗaukar nauyi: Designed for easy carrying and storage without compromising beam distance.
- Gina Mai Dorewa: Features a water-resistant anodized aircraft-grade aluminum body, built to withstand outdoor conditions.
- USB-C mai caji: Conveniently recharges via USB-C, with a full charge typically achieved in about 4.5 hours.
- Smart Power Control: Ensures a seamless transition between light modes to optimize battery life.
5. Saita
5.1 Fara Cajin
- Locate the USB-C charging port on the flashlight. This is typically covered by a protective cap.
- Open the protective cap and insert the provided USB-C cable into the port.
- Haɗa dayan ƙarshen kebul na USB-C zuwa tushen wutan USB mai dacewa (misali, adaftar bango, tashar USB na kwamfuta).
- The charging indicator light will illuminate (often red) to show that charging is in progress. It will change color (e.g., green or blue) when fully charged.
- Cikakken caji yana ɗaukar kusan awa 4.5.
- Once charging is complete, disconnect the cable and securely close the protective cap to maintain water resistance.
Figure 1: The NEBO Luxtreme flashlight connected to a USB-C charging cable. The charging port is visible, indicating the device is ready for power input.
6. Umarnin Aiki
6.1 Kunnawa/Kashewa da Zaɓin Yanayin
- To turn the flashlight ON, press the power button located on the side of the flashlight.
- To cycle through the 4 available light modes, press the power button repeatedly while the flashlight is ON. The modes typically include High, Medium, Low, and Strobe.
- To turn the flashlight OFF, press and hold the power button for approximately 2 seconds, or cycle through all modes until the light turns off.
6.2 Smart Power Control
The NEBO Luxtreme features Smart Power Control, which allows for a smooth transition between light modes. This technology helps to conserve battery life by preventing abrupt power changes and optimizing output for each mode.
Figure 2: A person using the NEBO Luxtreme flashlight to illuminate a path, demonstrating its Smart Power Control for efficient lighting.
6.3 Beam Characteristics
The Luxtreme flashlight is engineered with advanced optics to produce an ultra-long, focused beam capable of reaching up to 900 meters. It also offers a versatile wider beam for close-range illumination, adapting to various user needs.
Figure 3: The NEBO Luxtreme flashlight casting a powerful, long-distance beam across a body of water towards distant mountains under a starry sky.
Figure 4: A person using the NEBO Luxtreme flashlight to illuminate the immediate area along a lake shore, showcasing its versatile wider beam for close-range lighting.
7. Kulawa
7.1 Tsaftacewa
- Shafa jikin tocila da laushi, damp zane.
- For the lens, use a lens cleaning cloth and solution to avoid scratches.
- Ensure the charging port cap is clean and free of debris before closing to maintain water resistance.
7.2 Kula da Baturi da Ajiya
- Recharge the battery regularly, even if not in frequent use, to maintain optimal battery health.
- Ajiye fitilar a wuri mai sanyi, busasshiyar nesa da hasken rana kai tsaye da matsanancin zafi.
- Don adanawa na dogon lokaci, yi cajin batirin zuwa kusan kashi 50% don tsawaita rayuwarsa.
Figure 5: The NEBO Luxtreme flashlight operating effectively in the rain, demonstrating its water-resistant design.
8. Shirya matsala
| Matsala | Dalili mai yiwuwa | Magani |
|---|---|---|
| Flashlight does not turn ON. | Ƙananan ko ƙarancin baturi. | Charge the flashlight using the provided USB-C cable. |
| Fitowar haske ba ta da ƙarfi. | Ƙananan matakin baturi. | Yi cajin baturi. |
| Hasken walƙiya ba ya caji. | Kebul ko tushen wutar lantarki mara kyau; toshewar tashar caji. | Try a different USB-C cable or power source. Ensure the charging port is clean and free of debris. |
| Shigar ruwa bayan an fallasa shi. | Charging port cap not securely closed. | Ensure the charging port cap is always tightly sealed when not charging. Allow the flashlight to dry completely before attempting to use or charge again. |
9. Ƙayyadaddun bayanai
| Siffar | Daki-daki |
|---|---|
| Lambar Samfura | Saukewa: FLT-1008 |
| Fitowar Haske | 500 Lumens (Max) |
| Nisa Tsayi | Har zuwa mita 900 |
| Nau'in Tushen Haske | LED |
| Tushen wutar lantarki | Ana Karfin Batir (Batir Lithium ion 1 ya haɗa) |
| Ƙarfin baturi | 4,000mAh |
| Lokaci na Siyarwa | Kimanin awanni 4.5 (ta hanyar USB-C) |
| Kayan abu | Anodized Aircraft-Grade Aluminum |
| Matsayin Juriya na Ruwa | Resistant Ruwa |
| Launi | Guguwar Grey |
| Girman samfur | 4"D x 4"W x 7"H |
| Nauyin Abu | 1.2 fam |
| Shawarwari Amfani | Camping, hiking, hunting |
| UPC | 645397001041 |
10. Bidiyon Samfur na hukuma
NEBO Luxtreme Flashlight Overview
Wannan bidiyon yana ba da cikakken bayaniview of the NEBO Luxtreme flashlight, highlighting its key features and design.
Nebo Luxtreme Half-Mile Beam Demonstration
Watch this video to see the impressive half-mile beam capability of the Nebo Luxtreme flashlight in action.
11. Garanti da Tallafawa
11.1 Bayanin Garanti
The NEBO Luxtreme 500-Lumen LED Flashlight comes with a 1-year limited warranty from the date of purchase. This warranty covers manufacturing defects and workmanship under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or normal wear and tear. Please retain your proof of purchase for warranty claims.
11.2 Tallafin Abokin Ciniki
For technical assistance, warranty claims, or general inquiries, please visit the official NEBO website or contact their customer service department. Contact details can typically be found on the product packaging or the manufacturer's website.
