MAONO PD100W Wireless/USB Dynamic Microphone Instruction Manual

Gabatarwa

The MAONO PD100W is a versatile wireless and USB dynamic microphone designed for high-quality audio recording, streaming, podcasting, and gaming. It offers dual-mode connectivity, advanced noise reduction, customizable RGB lighting, and real-time monitoring for a professional audio experience.

Me ke cikin Akwatin

• Wireless Dynamic Microphone with Stand
• RX USB-C Receiver
• 2-in-1 USB-A&C to USB-C Charging Cable
• 2-in-1 USB-A&C to USB-C Adapter
• Manual mai amfani

Image: Contents of the MAONO PD100W package. Includes the microphone with its desk stand, a USB-C receiver, a USB-A&C to USB-C charging cable, a USB-A&C to USB-C adapter, and the user manual.

Saita Umarnin

Hada makirufo

1. Attach the microphone to the included desk stand by screwing it onto the 3/8-inch or 5/8-inch thread.
2. Ensure the microphone is securely fastened to prevent accidental movement.

Hoto: Rufewa view of the microphone's base showing the dual-thread design (3/8-inch and 5/8-inch) for attaching to the desk stand or other compatible mounts.

Haɗa zuwa Na'urori

The MAONO PD100W supports both wireless (2.4G) and USB wired connections.

Yanayin Mara waya (2.4G)

1. Insert the RX USB-C Receiver into your device's USB-C port (PC, Laptop, Phone, PS5). Use the provided 2-in-1 USB-A&C to USB-C Adapter if your device only has a USB-A port.
2. Press and hold the power button at the bottom of the microphone to turn it on. The RGB lights will illuminate.
3. The microphone and receiver should automatically pair. A stable indicator light on the microphone confirms a successful connection.

Image: A visual guide illustrating how to connect the MAONO PD100W microphone to various devices (PC, laptop, phone, PS5) using both wireless (via USB-C receiver) and wired (via USB-C cable) methods.

Yanayin Wayar USB

1. Connect the microphone to your device (PC, Laptop, Phone, PS5) using the provided 2-in-1 USB-A&C to USB-C Charging Cable.
2. The microphone will be recognized as an audio input device. No additional drivers are typically required for basic functionality.

Umarnin Aiki

Kunna/Kashe Wuta

Press and hold the power button located at the bottom of the microphone to turn it on or off.

Mute Aiki

Tap the touch-sensitive mute button on the microphone for instant silence. The RGB lights will turn off when muted, providing a visual indicator.

Rage Hayaniya

The microphone features one-click noise reduction with 3 adjustable levels (low, medium, high). Press the dedicated noise reduction button to cycle through the levels or activate/deactivate the feature. This helps isolate background noises from your computer, keyboard, and fan.

Gain and Volume Control

Use the 2-in-1 smart knob to adjust both microphone gain and headphone volume. Short press the knob to switch between controlling gain (white indicator light) and headphone volume (blue indicator light).

Kulawa na Gaskiya

The 3.5mm headphone jack allows you to monitor your audio in real-time, ensuring optimal sound quality during recording or streaming.

Hasken RGB na musamman

The microphone features customizable RGB lighting with multiple colors and 3 lighting modes. Press the RGB switch button to cycle through 8 dynamic colors or turn the lighting off. Brightness and color customization can also be managed via the Maono Link software.

Image: A user interacting with the MAONO PD100W microphone, highlighting its customizable RGB lighting feature. The microphone is placed on a desk with a computer setup.

Maono Link Software

The accompanying Maono Link software, compatible with Windows, iOS, and Android, allows for fine-tuning of various microphone settings:

• Daidaita EQ: Customize the equalizer settings for your desired sound profile.
• Rage Amo: Adjust noise cancellation levels beyond the hardware buttons.
• Tasirin RGB: Personalize lighting effects, brightness, and color.
• Saitattun Sauti: Utilize one-click presets for vocal recording, streaming, and podcasting.
• Alamar baturi: Monitor real-time battery levels.

Image: Screenshots of the Maono Link software interface on both a laptop and a smartphone, displaying options for microphone gain, monitor volume, noise reduction, scene modes, and RGB lighting controls.

Rayuwar Baturi

The MAONO PD100W features a built-in 1500 mAh rechargeable battery, offering up to 40 hours of continuous use on a single charge. An orange indicator flashes when the battery level drops below 20%. Real-time battery monitoring is available via the Maono Link software.

Ƙayyadaddun bayanai

Shirya matsala

• Babu Fitar Sauti: Ensure the microphone is powered on and correctly connected (either via USB cable or the wireless receiver). Check your device's audio input settings to confirm the MAONO PD100W is selected. Verify that the microphone is not muted and the gain is adequately adjusted.
• Rashin ingancin Sauti: Adjust the microphone gain to an appropriate level to avoid clipping or low volume. Utilize the built-in noise reduction feature or the Maono Link software to minimize background noise. Ensure the microphone is positioned correctly, ideally 2-6 inches from your mouth.
• Matsalolin Haɗin Mara waya: Ensure the RX USB-C Receiver is securely plugged into your device. If issues persist, try re-pairing the microphone and receiver (refer to the user manual for specific pairing instructions). Check for potential interference from other 2.4Ghz devices.
• Fitilar RGB Ba Sa Aiki: Press the RGB switch button to cycle through modes or turn them on. Check settings in the Maono Link software.
• Zubar da Batir cikin Sauri: Ensure the microphone is fully charged before use. Monitor battery levels via the Maono Link software. Reduce RGB brightness or turn off RGB lights if extended battery life is needed.

Kulawa

• Tsaftacewa: Yi amfani da laushi, bushe bushe don tsaftace jikin makirufo. Ka guji yin amfani da sinadarai masu tsauri ko kayan shafa.
• Ajiya: Ajiye makirufo a wuri mai sanyi, busasshiyar nesa da hasken rana kai tsaye da matsanancin zafi lokacin da ba a amfani da shi.
• Kulawar Baturi: For optimal battery longevity, avoid fully discharging the battery frequently. Charge the microphone regularly, even if not in constant use.

Garanti da Taimako

MAONO products typically come with a manufacturer's warranty. Please refer to the warranty card included in your product packaging or visit the official MAONO website for detailed warranty information and customer support options. For additional product function tutorials and FAQs, please visit https://faq.maono.com.
